Yamaha MG16XU Mixer with USB and FX


RRP $829.99
SAVE $100.99

or 4 payments of $182.25 with Info

Quality Mixer for Studio or Stage

The Yamaha MG16XU is a 16 channel analogue mixer designed for both home recording studios as well as live sound applications. It features 10 “D-Pre” mic preamps, 8 mono and 4 stereo line inputs, 4 aux outputs, 4 group busses as well as 1 stereo bus. Each mic input features a 80Hz HPF, 3 band EQ with sweepable mid, level and pan controls as well as 48v Phantom Power for recording condenser microphones. Channels 1 to 8 also include Yamaha’s “One Knob Compression”. The 3 stereo channels can either accept ¼” jack or RCA plugs and include a 3 band EQ, level and pan controls.

The MG16XU’s effects engine features 24 effects, adjustable on each channel via an effects send. There is both a stereo XLR and TRS output for connecting to PA or monitor speakers as well as a headphone output. There is also an additional monitor output as well as USB for recording 24bit/192kHz to a computer. The MG16XU is ideal for those needing a simple yet comprehensive analogue mixer that is robust and affordable.

Includes Cubase AI software.

Brand Yamaha


  • 16 Channels
  • 10 Microphone Inputs (XLR/Jack) with +48V Phantom power (Channel 1-8 with built-in compressor)
  • 3 Band EQ with semi parametric
  • High-Pass Filter and 26 dB Pad Switch
  • SPX Effect processor with 24 programs
  • 4 Stereo Inputs (jack) with 3-Band EQ
  • XLR-Output
  • 2 Group BUS outputs
  • 4 AUX-Way on each channel
  • USB with 2 Stereo In-/Output (compatible with iPad Version 2 or higher, Camera Connection Kit required)
  • Dimensions: 444 x 130 x 500 mm
  • Weight: 6.8 kg
  • Including Rack Mount Kit and Cubase AI DAW Software as Download


Incl. Effects Unit Yes
19" Rack Compatible Yes
Mic Preamps 10
Stereo Inputs 4
Aux 4
Phantom power Yes
Integrated Power Supply Yes
Parametric No
Digital Interface Yes
