Sennheiser EW 500 FILM G4 Portable Wireless Combo Set (Frequency Band A)

SKU: EW500-FILM-G4-AS

$1,599.00
RRP $1,999.00
SAVE $400.00
Normally Available Within 7 Days
Share:



Portable Wireless for your live location

The Sennheiser EW 500 FILM G4 Portable Wireless Combo Set is right at home on a live stage in your favourite venue or at major festivals, in houses of worship, and in the theatre. Sound engineers and avid users love its flexibility and versatility whereas more casual users will adore how easy it is to setup, allowing them to fully concentrate on their main goal: connecting with their audience.  Renowned sound engineers rely on ew 500 G4's flexibility, especially when handling multi-channel settings on the world's music stages. Up to 88 MHz bandwidth, up to 32 channels. Ethernet connection for Wireless Systems Manager (WSM) control software included for advanced frequency coordination in multi-channel setups.

Covers all sorts of applications on the set: The 48V phantom-power equipped SKP 500 turns all wired mics into a wireless transmitter, the MKE 2 Gold is a state-of-the-art professional clip-on microphone offering the highest speech intelligibility.

Frequency range:  AS 520 - 558 MHz



Sennheiser EW 500 FILM G4 Features at a Glance:

  • Highly versatile solution for professional film sound: Rugged all-in-one wireless system for professional interviews and recording
  • Professional sound and excellent construction quality
  • Easy to use and fast setup time
  • Easy and flexible wireless synchronisation between transmitter and receiver via infrared
  • Up to 88 MHz bandwidth, up to 32 channels
  • Range: up to 100 meters / 330 feet
  • Increased RF output power (10/30/50 mW)
  • Up to 8 hours of operation time
  • With 48 V phantom powering



What's in the box?

  • EK 500 G4 camera receiver
  • SK 500 G4 bodypack transmitter
  • SKP 500 G4 pro plug-on transmitter
  • MKE 2 clip-on microphone
  • 4 AA batteries
  • CL 1 3.5 mm jack cable
  • CL 500 XLR to 3.5 mm jack adapter cable
  • CA 2 camera adapter
  • fur windscreen for MKE 2
  • quick guide
  • safety guide
  • manufacturer declaration sheet

Sennheiser EW 500 FILM G4 Tech Specs:

 EK 500 G4

    Dimensions:        Approx. 82 x 64 x 24 mm

    Compander:        Sennheiser HDX

    THD, total harmonic distortion"        ≤ 0.9 %

    Weight:        (incl. batteries) approx. 130 g

    Audio output"        3.5 mm jack socket: +17 dBu (mono, balanced)

    Signal-to-noise ratio:        Line: ≥ 110 dBA, Phones: approx. 90 dBA

    Switching bandwidth:        up to 88 MHz

    Peak deviation:        ±48 kHz

    Nominal deviation:        ±24 kHz

    Operating time:        Typically 8 h

    Modulation:        Wideband FM

    Power supply:        2 AA batteries, 1.5 V or BA 2015 accupack

    Current consumption:        at nominal voltage: typ. 140 mA
        with receiver switched off: ≤ 25 µA

    Adjacent channel rejection:        Typically ≥ 65 dB

    Intermodulation attenuation:        Typically ≥ 65 dB

    Powering:        3 V battery / 2.4 V rechargeable battery

    Receiving frequency:        Max. 3520 receiving frequencies, adjustable in 25 kHz     steps, 20 frequency banks, each with up to 32 factory-preset channels, no        intermodulation, 6 frequency banks with up to 32 programmable channels

    RF sensitivity:        < 1.6 μV for 52 dBA eff S/N

    Squelch:        low: 5 dBµV, middle: 15 dBµV, high: 25 dBμV

    Temperature Range:        -10 °C to +55 °C

    Receiver Principle:        Adaptive diversity

    Blocking:        ≥ 70 dB

    Frequency range:        AS: 520 - 558 MHz

SK 500 G4

    Dimensions:        Approx. 82 x 64 x 24 mm

    Compander:        Sennheiser HDX

    THD, total harmonic distortion:        ≤ 0.9 %

    Weight:        (incl. batteries) approx. 160 g

    Signal-to-noise ratio:        ≥ 115 dBA

    RF output power:        switchable: Low: typ. 10 mW, Standard: typ. 30 mW,     High: typ. 50 mW

    Switching bandwidth:        up to 88 MHz

    Peak deviation:        ±48 kHz

    Nominal deviation:        ±24 kHz

    Operating time:        Typically 8 h

    Modulation:        Wideband FM

    Power supply:        2 AA batteries, 1.5 V or BA 2015 accupack

    Current consumption:        at nominal voltage: typ. 180 mA
    with transmitter switched off: ≤ 25 µA

    Input impedance:        40 kΩ, unbalanced / 1 MΩ

    Max. Input voltage:        3 Veff

    Powering:        3 V battery / 2.4 V rechargeable battery

    Transmission frequency:        Max. 3520 frequencies, adjustable in 25 kHz steps,     20 frequency banks, each with up to 32 factory-preset channels, no     intermodulation, 6 frequency banks with up to 32 programmable channels

    AF frequency response:        Mic: 80 – 18,000 Hz, Line: 25 – 18,000 Hz

    Temperature Range:        -10 °C to +55 °C

    Frequency stability:        ≤ ±15 ppm

SKP 500 G4

    Dimensions:        Approx. 105 x 43 x 43 mm

    Compander:        Sennheiser HDX

    THD, total harmonic distortion:        ≤ 0.9 %

    Weight:        (incl. batteries) approx. 195 g

    Signal-to-noise ratio:        ≥ 120 dBA

    RF output power:  switchable:
    Low: typ. 10 mW,
    Standard: typ. 30 mW,
    High: typ. 50 mW

    Switching bandwidth:        up to 88 MHz

    Peak deviation:        ±48 kHz

    Nominal deviation:        ±24 kHz

    Operating time:        Typically 8 h

    Modulation:        Wideband FM

    Power supply:        2 AA batteries, 1.5 V or BA 2015 accupack

    Current consumption:        at nominal voltage: typ. 210 mA
    with transmitter switched off: ≤ 25 µA

    Input impedance:        68 kΩ, unbalanced

    Max. Input voltage:        6 Veff

    Powering:        3 V battery / 2.4 V rechargeable battery

    Transmission frequency:        Max. 3520 frequencies, adjustable in 25 kHz steps,     20 frequency banks, each with up to 32 factory-preset channels, no     intermodulation, 6 frequency banks with up to 32 programmable channels

    AF frequency response:        80 – 18,000 Hz

    Temperature Range:        -10 °C to +55 °C

    Frequency stability:        ≤ ±15 ppm

MKE 2

    Connector:        3.5 mm jack

    Frequency response:        20 to 20.000 Hz ± 3 dB

    Max. sound pressure level:        142 dB

    Cable length:        approx. 1.60 m

    Transducer principle:        pre-polarized condensor microphone

    Pick-up pattern:        omni-directional

    Sensitivity in free field, no load (1kHz):        5 mV/Pa, ± 3 dB

    Equivalent noise level:        26 dB

    Equivalent noise level weighted as per CCIR 468-3:        39 dB



SKU EW500-FILM-G4-AS
Model # 508145
Brand Sennheiser

2 Years

Sennheiser EW 500 FILM G4 Features:

  • Highly versatile solution for professional film sound: Rugged all-in-one wireless system for professional interviews and recording
  • Professional sound and excellent construction quality
  • Easy to use and fast setup time
  • Easy and flexible wireless synchronisation between transmitter and receiver via infrared
  • Up to 88 MHz bandwidth, up to 32 channels
  • Range: up to 100 meters / 330 feet
  • Increased RF output power (10/30/50 mW)
  • Up to 8 hours of operation time
  • With 48 V phantom powering
