Neumann KH 80 DSP 4" Powered Studio Monitor (Single)

SKU: KH80

$749.00
RRP $999.00
SAVE $250.00
Share:



Neumann Monitors - Controlled from your Network

You already know Neumann as a world-standard microphone producer, and the KH series of monitors have positioned them as an authority in the monitoring world...well they've raised the bar again with the release of the KH80 series which is the first studio monitor with DSP (Digital Signal Processing).Thanks to the  “Neumann.Control” software, in the future the KH 80 DSP two-way near-field studio monitor will be able to fully calibrate itself to the room. This can be performed either automatically (Precision Alignment), with some simple questions (Guided Alignment), or adjusted with complete flexibility using the built in 8-band fully parametric equalizer (Manual Alignment).

The DSP feature means that you can control them via a central network right from your tablet or computer, which means it makes the KH80 ideal for surround monitoring configurations.

We have the Solution to your biggest variable - your room.

It might be a project studio, an OB van, or just a corner of a building: The room defines the sound right? For a really true sound, you normally need expensive equipment plus plenty of time and expertise to align it correctly – or smart algorithms. Our DSP engine optimizes the sound output, delivering quality way above price-tag. And you do not need to be an expert use it. The KH 80 DSP is ready for use with our Neumann.Control software, which allows you to control and optimize the system.

Features:

  • 4” + 1” drivers powered by high efficiency 120 and 70 W amplifiers
  • Computer modeled and optimized drivers and MMD™ waveguide
  • 57 Hz (-3 dB) bass extension and 108.8 dB SPL at 1 m
  • DSP engine with standard IP networking and Neumann control software



Neumann KH80 Studio Monitors - Worthy of the Neumann badge

Acoustical

-6 dB free field frequency response: 53 Hz … 22 kHz, ± 6 dB

-3 dB free field frequency response: 57 Hz … 21 kHz, ± 3 dB

Pass band free field frequency response: 59 Hz … 20 kHz, ± 2 dB

Self-generated noise (with input gain set to 100 dB for 0 dBu): < 20 dB(A) bei 10 cm

Max. SPL in full space at 3% THD at 1m (averaged between 100 Hz and 6 kHz): 102,8 / 108,8 dB SPL



Electronics

Input: XLR, analog electronically balanced

Controller design: Digital, active

Crossover frequency, slopes: 1.8 kHz, 48 dB/oct, 8th order

Bass amplifier, cont.(peak) output power*: 150 W (130 W)

Treble amplifier, cont.(peak) output power: 55 W (70 W)

Mains Power Supply, voltage; frequency: 100-240 V~; 50/60 Hz, with standby



Mechanics

Drivers: 100 mm (4"), 25 mm (1"), with integrated black metal grilles

Mounting points: 2 x M6 threaded inserts with 70 mm spacing on back panel

Product dimensions (height x width x depth), mm (inches): 233 x 154 x 194 mm (9 1/8" x 6" x 8 5/8")

Product weight: 3.5 kg (7 lbs 11 oz)

SKU KH80
Model # 506834
Brand Neumann

Features:

  • 4” + 1” drivers powered by high efficiency 120 and 70 W amplifiers
  • Computer modeled and optimized drivers and MMD™ waveguide
  • 57 Hz (-3 dB) bass extension and 108.8 dB SPL at 1 m
  • DSP engine with standard IP networking and Neumann control software
