KORG Minilogue XD Polyphonic Analogue Synthesizer


RRP $1,349.00
SAVE $350.00

or 4 payments of $249.75 with Info

The KORG Minilogue XD is a powerful next-generation analog synthesizer with huge potential for sound design and performance.

KORG Minilogue XD Polyphonic Analogue Synthesizer

Korg wanted to deliver a next-generation analog synthesizer for a new generation of musicians new to analog synthesis. That dream was realized in the development of the minilogue, which instantly made the analog synthesizer approachable.

An evolved next-generation analog synthesizer with huge potential for sound design and performance. In addition to emphasizing the same real analog sound and joy of controlling an electronic musical instrument offered by the original minilogue, the minilogue xd newly adds a digital multi-engine, effects, a powered-up sequencer, and micro tuning functionality, further expanding the possibilities for sound design and performance potential.

Analog synthesizer circuit that shatters expectations for its class

Four-voice polyphonic analog synthesis. The analog synthesizer circuit of the minilogue, whose genuine analog sound had a huge impact on the synth world, has been further developed for the minilogue xd.

Voice structure of minilogue xd is 2VCO + MULTI ENGINE, 1VCF, 2EG, 1VCA, and 1LFO. In addition to the distinctive circuits found in the series, such as wave shaping to shape the overtones of the oscillator and a sync/ring switch, there's also cross modulation, a sharp two-pole filter, and a drive switch that adds thickness and drives signal into minilogue xd’s filter. Every parameter has been tuned in detail based on what musicians want out of their synth. The sounds range from the warm pads typical of analog to fat basses and crisp lead sounds, covering every situation. Programs that you create can also be saved in the unit. Out of the box, minilogue xd comes loaded with 200 presets, and a total of 500 programs can be saved.

Equipped with a digital multi-engine

The additional sound design possibilities of digital sound are delivered by the multi-engine that's provided as a third oscillator in addition to the two analog VCOs. This engine, which is equipped with three different types of sound generator (noise, VPM, and user slot) lets you take advantage of a sonic character that's different than analog, and use it at the same time as the analog engine, infinitely expanding the potential of hybrid sound design. The noise generator provides four types of noise that are indispensable for percussive sounds or for sound effects. You can use the digital filter to directly change the color of the noise. Minilogue xd’s multi-engine features a VPM (Variable Phase Modulation)/FM oscillator with a two-operator structure. It can produce sharp, metallic sounds with complex overtones beyond the possibilities offered by analog systems. With 16 types of oscillator and a SHAPE knob control, you'll be able to create complex sounds intuitively.

User oscillators allow you to load your own oscillator programs that you created or obtained via the internet. There are 16 user slots, as well as one type of morphing wavetable oscillator provided as a preset. The step sequencer provides 16 steps, and supports both realtime recording and step recording. You can use the 16 step buttons to select a step directly, allowing quick editing to replace the pitch of a step or to mute it, or even improvisatory performances. Motion sequence lets you record the movements of up to four knobs, adding time-varying change to the sound, and you can record not only smooth changes in value but also values that change precisely at each step.


Buy your Korg Minilogue XD from your Korg experts in Brisbane - Musiclab!

For more information on the Korg Minilogue XD, please visit the Manufacturer's Website.

Korg Minilogue XD Specs:


  •  AC adapter (DC9 V)

  • Power Consumption - 8 W

  • DAMPER jack (half damper is not supported)

  • USB B jack

  • MIDI OUT jack

  • MIDI IN jack

  • SYNC OUT jack (3.5 mm [1/8"] mini jack, output level 5 V)

  • SYNC IN jack (3.5 mm [1/8"] mini jack, maximum input level 20 V)

  • CV IN 1, CV IN 2 jacks (3.5 mm [1/8"] monoural mini jack, Input voltage: -5 V – +5 V (Modulation mode), -3V – +5 V (CV/Gate mode)

  • OUTPUT L/MONO, R jacks (monaural phone jack unbalanced)

  • Headphone jack (Stereo phone jack)


Barcode # 4959112187986
Brand Korg

12 Months (or 3 years with registration)

Korg Minilogue XD Features:


  • 37-keys (Slim-key, velocity sensitive)

  • Sound Generation -  Analogue sound generator + Multi digital sound generator (Noise, VPM, User)

  • Maximum Polyphony - 4 voices

  • 500 voices (more than 200 preload, 300 user programs).

  • Each program provides a program sort function that includes voice mode settings.

  • Voice Mode - 4 (POLY, UNISON, CHORD, ARP / LATCH).

  • The VOICE MODE DEPTH setting allows different parameters to be varied for each mode.

  • Sequencer - 16-step polyphonic sequencer motion sequence can be used on up to four parameters
