ZOOM H6 Handy Recorder (Black)

SKU: ZOOMH6BK

Have a Question

The Zoom H6 Black Version is capable of handling a vast array of recording situations from live sound recording to professional broadcasts and is arguably the most professional portable recorder ever. The H6 includes an X/Y capsule features 2 cardoid mics, adjustable between 90 and 120 degrees for a wide but focused stereo image. Also available is a shotgun capsule for video recording, a shock-mounted X/Y capsule for minimising vibrations and handling noise as well as a dual XLR/TRS combo capsule to turn the H6 black into a 6-track recorder when more inputs are needed.

The H6 black features 4 combo input jacks for connecting microphones, instruments or line level sources, each with individual volume controls as well as a -20 dB pad for attenuating high level signals. Audio can be monitored through the built-in speaker or the headphone output and can also be sent to a DSLR camera via the line output. When connected to a computer the Zoom H6 acts as an audio interface and on-board processing allows audio to be recorded with effects, without latency. Up to 20 hours of audio at 24 bit/96 kHz can be recorded on just 4 AA batteries (included).

Podcast Anywhere

From the studio to remote locations, podcasts are produced everywhere. With inputs for every guest, the battery-powered H6 is a complete portable podcasting solution.

Unlimited Studio Time

The H6 is your personal music studio 24/7. With up to six* discrete line-level / mic-level inputs, plus the ability to overdub and more, the H6 provides the road from a great idea to the perfect track.

*Optional EXH-6 mic capsule required

p3>Sound for Every Scene

Featuring interchangeable mic capsules, four combo inputs and six tracks of quality recording, the H6 is ready to record on any set and in any scene the director throws at you.

For more detailed information on the array of interchangeable Mic capsules, click HERE.

Includes 4 AA batteries, Zoom H6, X/Y capsule and Cubase LE & Wavelab SE download access codes. Note no SD Card included.

24 Bit / 96 kHz
Sample Rate: 44.1, 48, 96 kHz (wav) / 44.1 kHz (mp3)
Up to 6 channels can be simultaneously recorded
Changeable clip-on microphone (optional)
4 XLR/jack microphone-/line inputs, expandable to 6 inputs (optional I/O module)
6/2 Channel USB audio interface
Supports SD/SDHC cards up to 32 GB, as well as SDXC cards up to 128 GB
Colour LCD
Built-in loudpspeaker
Powered via 4 AA batteries or USB
Connection: USB 2.0 (Type B)
Dimensions without microphone (W x D x H): 77.8 x 152.8 x 47.8 mm

What’s in the Box

Here's what comes included with the H6 Black.

H6 Handy Recorder
XYH-6 X/Y mic capsule
4x AA batteries
Quick Guide
Cubase LE & Wavelab LE software (download code)

For more detailed information on the Zoom H6 Black Handy recorder, please visit Zoom's website.

Recording Media:

SD Card: 16MB to 2GB
SDHC Card: 4GB to 32GB
SDXC Card: 64GB to 128GB

Inputs:

XYH-6 X/Y mic: Mic type: Unidirectional
Sensitivity: -41 dB, 1 kHz at 1 Pa
Input gain: -∞ to 46.5 dB
Max sound pressure input: 136 dB SPL

XYH-6 Mic/Line In:

Connector: 1/8" stereo mini jack
Input level: - ∞ to 46.5 dB
Input impedance: 2 k Ω
Plug-in power: 2.5V supported

Inputs 1 to 4:

MicConnectors: XLR / TRS combo jacks
(XLR: Pin 2 hot / TRS: Tip hot)
MicInput gain: (PAD OFF) -∞ to 55.5 dB
MicInput gain: (PAD ON) -∞ to 35.5 dB
MicInput impedance: 1.8kΩ or more
MicMax input level: +22 dBu (PAD ON)
MicPhantom power: +12V /+24V /+48V
(Phantom power can be turned on/off independently for Inputs 1 - 4)
MicEquivalent Input Noise (EIN): -120 dBu or less

Outputs:

Line Out : Jack type: 1/8" stereo mini jack
- Rated Output Level: -10 dBu when output load impedance is 10k Ω or more
Phone Out: Jack type: 1/8" stereo mini jack
- Output Level: 20 mW +20 mW into 32 Ω load
Built-in speaker: 400mw 8 Ω mono speaker

Recording Formats:

WAV:

Sampling frequency: 44.1/48/96 kHz
Bit rate: 16/24
(Mono/Stereo, BWF-compliant)
Maximum simultaneous recording tracks: 8 (L/R + INPUT 1 to 4 + L/R backup)
(Backup recording: -12dB lower than set L/R input gain

MP3:

Sampling frequency: 44.1kHz
Bit Rate: 48/56/64/80/96/112/128/160/192/224/256/320kbps
Maximum simultaneous recording tracks: 2

Display:

LCD Screen: 2.0-inch full color LCD (320 x 240 pixels)

USB Mass Storage Class operation:

Class: USB2.0 High Speed

Audio Interface operation: Multi-track mode:

Class: USB2.0 High Speed
Inputs / Outputs: 6 / 2
Sampling frequency: 44.1/48kHz/96kHz
Bit rate: 16/24 bit
USB bus powered operation possible

Battery Life:

Over 20 hours (with alkaline battery, continuous recording)

Dimensions and Weight:

H6: 77.8mm (W) x 152.8mm (D) x 47.8mm (H), 280g
XYH-6: 78.9mm (W) x 60.2mm (D) x 45.2mm (H), 130g

SKU	ZOOMH6BK
Brand	Zoom

1 Year

Interchangeable input capsules
Six-track simultaneous recording
Four mic/line inputs with XLR/TRS combo connectors
Gain control knobs and -20dB pads for each input
Supplied XYH-6 X/Y capsule provides secondary input via a stereo ⅛” Mic/Line In mini phone jack
Phantom power for all main inputs: +12/+24/+48V
Large full-color, angled LCD display
Records directly to SD, SDHC and SDXC cards up to 128GB
Up to 24-bit /96kHz audio in BWF-compliant WAV or a variety of MP3 formats
Auto-record, Pre-record and Backup-record functions mean that you'll never miss that perfect take
Built-in effects, including low-cut filtering, compression, and limiting
Multichannel and stereo USB audio interface for PC/Mac/iPad
Accepts standard AA alkaline or NiMH rechargeable batteries
Over 20 hours of operation with 4 AA alkaline batteries
