Universal Audio Apollo X8P 18x22 Thunderbolt 3 Audio Interface - Heritage Edition

SKU: APOLLOX8PH

$6,099.00
Share:

Apollo x8p allows music engineers, producers, and project studios to track, overdub, and mix with elite-class A/D and D/A conversion, HEXA Core UAD plug-in processing, Dual-Crystal clocking, and 7.1 surround sound monitoring.




Universal Audio Apollo X8P 18x22 Thunderbolt 3 Audio Interface - Heritage Edition

Please note: this unit requires a Thunderbolt cable; one is not provided with the unit. Also note, the Apollo Solo Heritage Edition has a Thunderbolt 3 Connector; call us if you need clarification or assistance when purchasing.

The new Apollo Heritage Edition gives you a premium software suite with 5 award-winning UAD plug‑ins titles, including the full Collections from Teletronix,® Fairchild,® Pultec,® Helios,® and UA. These plug-ins are what has built the UA reputation for analog modeling over the past decade and include some of the most renowned vintage compressors, EQs, mic preamps, and reverbs.

Apollo x8p allows music engineers, producers, and project studios to track, overdub, and mix with elite-class A/D and D/A conversion, HEXA Core UAD plug-in processing, Dual-Crystal clocking, and 7.1 surround sound monitoring — all in a sleek rackmount Thunderbolt 3 audio interface for Mac or Windows.

Built upon UA’s 60-year heritage of audio craftsmanship, this 18 x 22 interface laps the competition with eight Unison™-enabled mic preamps, all-new HEXA Core processing — yielding 50% more DSP for running UAD Powered Plug-Ins in real time — plus it includes LUNA Recording System, giving you a fully‑integrated music production application.

Elite-Class A/d and D/A Conversion

With thousands of hit songs and hundreds of Grammy-winning albums under their belt, Apollo interfaces are no strangers to tracking stellar-sounding records. To improve on the previous generation Apollo interfaces’ class-leading audio conversion, UA engineers obsessively auditioned the latest A/D and D/A converters — ultimately pairing elite-class 24-bit/192 kHz converters with all-new analog circuitry for an ultra-pristine signal path.

The Apollo X series also introduces new Dual-Crystal clocking — featuring dedicated crystals for 44.1/88.2/176.4k and 48/96/192k sample rates — resulting in stunningly low jitter, measured at less than 10 picoseconds. This translates into pure, artifact-free recordings and solid stereo imaging you can trust.

With 129 dB dynamic range and -119 dB THD+N, Apollo x8p’s open, natural sound rivals any dedicated high-end converter on the market — regardless of price — and is the perfect starting point for applying UAD processing.

Realtime UAD HEXA Core Processing

Apollo x8p features new HEXA Core processing, with six DSP chips and 50% more UAD plug-in processing power than previous Apollos. This lets you run more UAD plug-ins, whether you’re tracking in real time with channel strips from Neve, Manley, or API, or running high UAD plug-in counts when mixing in your DAW.

From the tube warmth of Pultec EQs on guitars to the musical tube limiting of the LA-2A on vocals, or the pump of a genuine 1176 or Fairchild 670 tube compressor on drums, your recordings will take a giant leap forward with a rich, three-dimensional analog sound that UAD plug‑ins provide.

Unison Technology: The Genuine Sound of API and Manley Preamps

Perfect for engineers, producers, and project studio owners, Apollo x8p features eight Unison-enabled mic preamps, letting you track large projects through exacting mic preamp emulations from Neve, API, Manley, Helios, SSL, and Universal Audio. A Universal Audio exclusive, Unison technology nails the tone of these sought-after tube and solid state mic pres — including their input impedance, gain stage “sweet spots,” and the component-level circuit behaviors of the original hardware.

The secret to Unison is its hardware-software integration between Apollo’s mic preamps and its onboard HEXA Core DSP Acceleration. Simply place a Unison preamp plug-in on your mic input in Apollo Console software, and it physically reconfigures the Apollo interface's impedance — so you can tap into the classic sounds of the world’s most recorded mic preamps.

LUNA Recording System

Apollo X series interfaces work with all major DAWs. But they become a fully integrated recording system with LUNA, Universal Audio’s groundbreaking music production application for Mac. Harness LUNA’s Accelerated Realtime Monitoring™ and power your workflow with a host of built-in features and optional extensions — from genuine Neve summing and integrated Studer tape, to inspiring LUNA instruments, and more.

Heritage Included PLugins

Helios Type 69 Preamp and EQ Collection
V76 Preamplifier
Oxide Tape Recorder
Teletronix LA-3A Audio Leveler
Fairchild Tube Limiter Collection
Teletronix LA-2A Classic Leveler collection
Pultec Passive EQ Collection
1176 Classic Limiter Collection
Pure Plate Reverb
UA 610 Tube Preamp & EQ Collection

For more information on the Universal Audio Apollo X8P Heritage Edition, please visit UA website.

Buy your Universal Audio Apollo X8P Heritage Edition Audio Interface at the right price, from your Universal Audio experts in Brisbane - Musiclab!

Apollo X8p Specs



Inputs



Combo Mic/Line Inputs 8 Balanced XLR/TRS
DB25 Line Inputs 8 Balanced via 25-pin D-sub
Instrument (Hi-Z) Inputs 2 Unbalanced ¼" TS
Digital Inputs (Optical TOSLINK) ADAT: 8 channels @ 44.1 – 96 kHz
ADAT: 4 channels @ 176.4 – 192 kHz
S/PDIF: 2 channels @ 44.1 to 96 kHz
(Switchable ADAT or S/PDIF)

A to D Conversion



Mic Preamps Dynamic Range: 122 dB (A-weighted)
THD+N: -115 dB (0.00019%)
Frequency Response: 20 Hz – 20 kHz, ±0.05 dB
Line Inputs Dynamic Range: 123 dB (A-weighted)
THD+N: -113 dB (0.00022%)
Frequency Response: 20 Hz – 20 kHz, ±0.04 dB

Outputs



DB25 Line Outputs 8 Balanced via 25-pin D-sub
Monitor Outputs 2 Balanced ¼" TRS
Headphone Outputs 2 Stereo ¼" TRS
Digital Outputs (Optical TOSLINK) ADAT: 8 channels @ 44.1 – 96 kHz
ADAT: 4 channels @ 176.4 – 192 kHz
S/PDIF: 2 channels @ 44.1 to 96 kHz
(Switchable ADAT or S/PDIF)

D to A Conversion



Line Outputs Dynamic Range: 127 dB (A-weighted)
THD+N: -118 dB (0.00011%)
Frequency Response: 20 Hz – 20 kHz, ±0.07 dB
Monitor Outputs Dynamic Range: 129 dB (A-weighted)
THD+N: -118 dB (0.00012%)
Frequency Response: 20 Hz – 20 kHz, ±0.06 dB
Headphone Outputs Dynamic Range: 125 dB (A-weighted)
THD+N: -102 dB (0.00080%)
Frequency Response: 20 Hz – 20 kHz, ±0.05 dB



SKU APOLLOX8PH
Model # UA-APX8P
Brand Universal Audio

Apollo X8p Features



  • 18 x 22 Thunderbolt 3 audio interface with class-leading 24-bit/192 KHz conversion (backwards compatible with Thunderbolt 1 & 2 on Mac)

  • Realtime UAD HEXA Core Processing for tracking through UAD plug-ins at near-zero latency, regardless of audio buffer size

  • 8 Unison-enabled mic preamps with realtime preamp emulations from Neve, API, SSL, Manley, Universal Audio, and more†

  • Surround monitor controller up to 7.1 format

  • Includes “Realtime Analog Classics Plus” UAD plug-in bundle featuring UA 610-B Tube Preamp; Legacy Pultec EQ, LA-2A, and 1176 compressors; Marshall Plexi Classic; Ampeg SVT-VR Classic and more

  • UAD HEXA Core processing onboard for additional mixing horsepower for Pro Tools, Logic, Cubase, Ableton, and other major DAWs

  • Combine up to 4 Thunderbolt-equipped Apollos and 6 total UAD devices

  • Selectable +24 dBu operation for easy compatibility with professional mixing consoles and tape machines

  • Convenient front panel monitoring functions including Alt Speakers, Talkback mic, and assignable Dim or Mono

  • Free, industry-leading technical support — on the phone and online — from knowledgeable audio engineers
