Sennheiser EW 300 G4-HEADMIC1-RC Wireless Headmic Set (Frequency Band A)

SKU: EW300-G4-HEADMIC1-RC-AS

$1,599.00
RRP $1,799.00
SAVE $200.00
Normally Available Within 7 Days
Share:



Wireless made Simple

With Sennheiser's ew 300 G4 includes everything you need for excellent vocal reproduction. The powerful professional SL-HEADMIC1 is the pro’s choice for lively lectures and speeches. Its high speech intelligibility makes the headset microphone – besides its good look – absolutely reliable. Remote mute switch available for the bodypack transmitter. With a user-friendly menu with convenient jog wheel provides fast access to everything, the setup is as easy as pushing the "sync" button. Of course there's also the increased bandwidth and power, remote operation, and backward compatibility with previous evolution systems.

Best choice for your business, and top of the class in education. The G4 300 Series uses the power of an increased switching bandwidth of up to 88 MHz. New frequency ranges allow to operate multi-channel setups with dozens of channels while securing reliable operation - despite digital dividend.

Freq Band A: 520 - 558 MHz



Key Features at a Glance:

  • Easy to use, fast setup time

  • Integrated network port allows control, monitoring and setup via Sennheiser Control Cockpit and WSM Software

  • Broad range of products and existing accessories (such as microphones) allows usage in any kind of environment

  • Up to 88 MHz bandwidth, up to 32 channels

  • Increased RF output power (10/30/50 mW)

  • Transmission Range: up to 100 meters / 330 feet

  • Compatible with wireless speaker system LSP 500 PRO

  • RC (remote control) switch available for the bodypack transmitter



Flexible applicability

Thanks to its great sound, reliable RF transmission and robust devices combined with the right accessories, ew 300 G4 is probably the most flexible wireless microphone system available. You can rely on it in any situation, in any application, in any location. It covers all professional audio demands and suits perfectly for any speech, lecture, conference, moderation or live performance on stage.



Broad UHF frequency range

Extending the known reliability and robust RF performance of the evolution wireless microphone family, ew 300 G4 now offers with up to 88 MHz an even increased switching bandwidth for easier channel setup. Eleven frequency variants between 470 and 865 MHz cover globally local regulatory specifics for flexible setups – be it mobile microphone usage or installed.



Multi-channel operation

evolution wireless is known for its outstanding performance in multi-channel operation. With switchable transmission power of up to 50 mW and the increased switching bandwidth of up to 88 MHz, ew 300 G4 covers all kinds of multi-channel setups for any kind of event indoors or outdoors. Together with the broad range of antenna components, even huge setups can be organized and optimized in a snap.



Remote controllability

For optimal operation of even large scaled setups, the entire ew 300 G4 system is remote controllable with Sennheiser’s state-of the-art software solutions. For installed setups, the Sennheiser Control Cockpit Software is the ideal tool for easy handling, campus wide control and maintenance of the entire ew 300 G4 system, while for mobile and stage applications Sennheiser's Wireless Systems Manager is the best choice.

Sennheiser EW3

The ew 300 G4 system

The ew 300 G4 system comprises of outstanding components and has now been optimized in its fourth generation. The ew 300 G4 system is available in three kinds of sets:

• Handheld Set featuring the MME 865 condenser capsule,
• Lavalier Set featuring the ME 2 condenser lavalier microphone,
• Headmic Set featuring the outstanding SL Headmic 1 headworn microphone.

Handheld and bodyback transmitter as well as the stationary receiver are also available as single components for individual configuration of your desire. The charging and antenna components round out the ew 300 G4 portfolio to provide best performance in operation and reliability in any application. A unique accessory is the LSP 500 PRO wireless loudspeaker system that is remote controllable via LSP 500 PRO App. ew 300 G4 enables LSP 500 PRO to be a fully wireless public address system for any speech or event.



What's in the Box?

  • EM 300-500 G4 true diversity receiver
  • SK 300 G4
  • SL Headmic 1
  • GA 3 rackmount set
  • power supply
  • 2 AA batteries
  • 2 rod antennas
  • quick guide
  • safety guide
  • manufacturer declaration sheet

Sennheiser EW 100 G4-HEADMIC1-RC Wireless Headmic Set Tech Specs:

EM 300-500 G4
  • Dimensions
    Approx. 202 x 212 x 43 mm
  • Compander
    Sennheiser HDX
  • THD, total harmonic distortion
    ≤ 0.9 %
  • Weight
    Approx. 980 g
  • Audio output
    6.3 mm jack socket (unbalanced): +12 dBu
    XLR socket (balanced): +18 dBu
  • Signal-to-noise ratio
    ≥ 115 dBA
  • Switching bandwidth
    up to 88 MHz
  • Peak deviation
    ±48 kHz
  • Nominal deviation
    ±24 kHz
  • Modulation
    Wideband FM
  • Power supply
    12 V DC
  • Antenna connector
    2 BNC sockets
  • Current consumption
    350 mA
  • Adjacent channel rejection
    Typically ≥ 75 dB
  • Intermodulation attenuation
    Typically ≥ 70 dB
  • Receiving frequency
    Max. 3520 receiving frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation, 6 frequency banks with up to 32 programmable channels
  • RF sensitivity
    < 2.5 μV for 52 dBA eff S/N
  • Squelch
    5 to 25 dBμV in steps of 2 dB
  • Equalizer
    Preset 1: Flat
    Preset 2: Low Cut (-3 dB at 180 Hz)
    Preset 3: Low Cut/High Boost (-3 dB at 180 Hz, +6 dB at 10 kHz)
    Preset 4: High Boost (+6 dB at 10 kHz)
  • Temperature Range
    -10 °C to +55 °C
  • Receiver Principle
    True diversity
  • Blocking
    ≥ 75 dB
  • Frequency range
    AS: 520 - 558 MHz
SK 300 G4
  • Dimensions
    Approx. 82 x 64 x 24 mm
  • Compander
    Sennheiser HDX
  • THD, total harmonic distortion
    ≤ 0.9 %
  • Weight
    (incl. batteries) approx. 160 g
  • Signal-to-noise ratio
    ≥ 115 dBA
  • RF output power
    switchable: Low: typ. 10 mW, Standard: typ. 30 mW, High: typ. 50 mW
  • Switching bandwidth
    up to 88 MHz
  • Peak deviation
    ±48 kHz
  • Nominal deviation
    ±24 kHz
  • Operating time
    Typically 8 h
  • Modulation
    Wideband FM
  • Power supply
    2 AA batteries, 1.5 V or BA 2015 accupack
  • Current consumption
    at nominal voltage: typ. 180 mA
    with transmitter switched off: ≤ 25 µA
  • Input impedance
    40 kΩ, unbalanced / 1 MΩ
  • Max. Input voltage
    3 Veff
  • Powering
    3 V battery / 2.4 V rechargeable battery
  • Transmission frequency
    Max. 3520 frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation, 6 frequency banks with up to 32 programmable channels
  • AF frequency response
    Mic: 80 – 18,000 Hz, Line: 25 – 18,000 Hz
  • Temperature Range
    -10 °C to +55 °C
  • Frequency stability
    ≤ ±15 ppm
SL Headmic 1
  • Connector
    3.5 mm jack plug or Sennheiser special connector (-4 variant)
  • Frequency response
    20 to 20,000 Hz ± 3 dB
  • Max. sound pressure level
    143 dB
  • Cable length
    1.6 m
  • Weight
    (without cable) approx. 7 g
  • Diameter
    of mic capsule: 3.3 mm
    of boom arm: 1.1 mm
  • Pick-up pattern
    omni-directional
  • Nominal impedance
    1 kΩ
  • Min. terminating impedance
    4.7 kΩ
  • Equivalent noise level
    27 dB(A)
  • Power supply
    4.5 to 15 V
  • Sensitivity
    5 mV/Pa ± 3 dB
  • Temperature Range
    Operation: -10 °C to 50 °C (14 °F to 122 °F)
    Storage: -20 °C to 70 °C (-4 °F to 158 °
SKU EW300-G4-HEADMIC1-RC-AS
Model # 508019
Brand Sennheiser

Sennheiser EW 100 G4-HEADMIC1-RC Wireless Headmic Set Features:



  • Easy to use, fast setup time

  • Integrated network port allows control, monitoring and setup via Sennheiser Control Cockpit and WSM Software

  • Broad range of products and existing accessories (such as microphones) allows usage in any kind of environment

  • Up to 88 MHz bandwidth, up to 32 channels

  • Increased RF output power (10/30/50 mW)

  • Transmission Range: up to 100 meters / 330 feet

  • Compatible with wireless speaker system LSP 500 PRO

  • RC (remote control) switch available for the bodypack transmitter
